Economy Work Arms 80 Nm Arm

Có: 0 sản phẩm trong giỏ

Economy Work Arms 80 Nm Arm
  • Mã SP: DBAIR-EWA80
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 4787
  • Arm length Two piece arm legth adjustable between 86.4 to 106.7 cm (34 to 42 in) Work Envelope Covers a 61 x 76.2 cm (24 x 30 in) horizontal rectangular work envelope Annodized aluminum construction Anti-corrosive and durable construction. Parallel link arm Outer portion of the arm is a dual parallel link arm designed for 50 cm (20 in) of vertical travel Tool holder The tool holder can handle tool diameters from .5 in (12.7 mm) up to 2.5 in (63.5 mm) and is adjustable for horizontal or vertical tool orientations. It can be ordered for bi-directional tilt (p/n 54033162) or single-directional tilt (p/n 54033196). Mounting Plates Mounting plates allow the unit to be mounted to a bench, wall, column or ceiling etc
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
    Arm length      Two piece arm legth adjustable between 86.4 to 106.7 cm (34 to 42 in)     Work Envelope      Covers a 61 x 76.2 cm (24 x 30 in) horizontal rectangular work envelope     Annodized aluminum construction      Anti-corrosive and durable construction.     Parallel link arm      Outer portion of the arm is a dual parallel link arm designed for 50 cm (20 in) of vertical travel     Tool holder      The tool holder can handle tool diameters from .5 in (12.7 mm) up to 2.5 in (63.5 mm) and is adjustable for horizontal or vertical tool orientations. It can be ordered for bi-directional tilt (p/n 54033162) or single-directional tilt (p/n 54033196).     Mounting Plates      Mounting plates allow the unit to be mounted to a bench, wall, column or ceiling etc
This two piece, light-duty torque arm can rotate 360 degrees on both pivots, has outstanding & adjustable horizontal and vertical coverage, is pneumatically controlled with a single precision regulator that can balance tools up to 13.6 kg (30 lb) at the end of the arm and handle torque reactions up to 80 Nm (60 ft-lb). The unit features roller bearings for smooth operation and an adjustable pivot spring to automatically return the arm to a "home" position after use.
