Torque Tubes 250 Nm Tube

Có: 0 sản phẩm trong giỏ

Torque Tubes 250 Nm Tube
  • Mã SP: DBAIR-TT250
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 4721
  • Smooth vertical travel

    Super linear bearings for effortless vertical travel and maintenance free operation
    Adjustable length reaction bar

    The IRZ series has an adjustable reaction bar between 48 in (1219 mm) and 72 in (1829 mm), at 2 in (50 mm) increments, to eliminate the need for extension tubes and to ensure proper positioning of unit
    Suspension kits

    Optional single or dual trolley suspension for suspending from an overhead rail system
    Optional Tool holders

    360 degree - 3 axis or fixed - 2 axis tool holder clamps are available
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
  • Smooth vertical travel

    Super linear bearings for effortless vertical travel and maintenance free operation

  • Adjustable length reaction bar

    The IRZ series has an adjustable reaction bar between 48 in (1219 mm) and 72 in (1829 mm), at 2 in (50 mm) increments, to eliminate the need for extension tubes and to ensure proper positioning of unit

  • Suspension kits

    Optional single or dual trolley suspension for suspending from an overhead rail system

  • Optional Tool holders

    360 degree - 3 axis or fixed - 2 axis tool holder clamps are available

Torque tubes allow parts to be lifted, lowered, moved and brought into optimum working position with minimal force required by the operator. This product, IRZ-TT-250, relieves the operator of both part weight and torque reaction up to 250 Nm, resulting in increased workplace productivity. The unit has 24 in (610 mm) of vertical travel and a 60 lb (27 kg) capacity.
