Clean air and compatible, non-combustible gases
Maximum range 0.1 ~ 50 m/s (Range dependant on probe type*)
Current output: DC 4~20mA (Max. load resistance: 250Ω)
Voltage output: DC 0~5V
(Rotary Switch selectable).
0~2, 0~5, 0~10, 0~25, or 0~50 m/s
Velocity Range: 0~2, 0~5, 0~10 m/s → Display Resolution: 0.01m/s Velocity Range: 0~25, 0~50 m/s → Display Resolution: 0.1m/s
DC 12~24V
Approx. 2.0W (Under the following conditions - power supply: 12V, air velocity: approx. 10m/s, using a unit with a display with probe model 0965-03.)
Power consumption rate is subject to change according to conditions such as air velocity, probe type and use of display.
Connection Wire Size
0.5 ~ 1.5 mm2
Operating Temperature Range
5 ~ 40°C
Storage
Temperature Range
-10 ~ 50°C
Approx. 128(W)×78(D)×30(H) mm
Weight
Approx. 320g (11oz.)
Operation Manual : 1, Main Unit Case: 1
Optional Accessory
