Technical Data
HV Generator
50 kV, max. 1.2 mA current, software controlled
X-ray tube
Micro focus tube, W-target, Spot 85 µm x 85 µm, glass window
X- ray power
max. 50 VA, applications optimised
Single collimator
i. e. 0.1 mm or 0.3 mm or 0.1 mm x 0.3 mm
Collimator changer
Four positions, programmable and motorised
Sample Stage (Option)
a) Programmable and motorized X 300 mm, Y 250 mm, Z 180 mm, Easy Load, max. load 5 kg
b) Programma ble and motorized X 300 mm, Y 250 mm, Z 180 mm, max. load 20 kg
Sample positioning
Joy Stick, Point & Shoot, Laser, Auto- focus
Video system
Colour video system, field of view 2 x 1.5 mm and 4 x 3 mm
Magnification
appr ox. 40 x and 80 x
Radiation safety
PTB tested, totally fail safe system
Chamber
H 67 cm, B 60 cm, D 75 cm, slotted sample chamber
Sample Chamber
Useable max. H 35 cm, W 60 cm, D 50 cm
Mains supply
110 V / 230 V 60 Hz / 50 Hz
X-MasteR-Software
Operation system with WINDOWS 2000 / XP using modern PCTechnology
µ-MasteR
Evaluation module for coating thickness measurement
Fun-MasteR
Calibration module for fundamental parameter mathematics
Element-MasteR
Standardless qualitative and quantitative mater ial analysis for up to 20 elements
%-MasteR
Precise quantitative material analysis for up to 8 elements simultaneously with statistics
Liquid-MasteR
Plating bath analysis
Data-Maste R
Data base and statistic soft ware with long term documentation
Repor t-Master
Software module to create customised reports
