R1000 r-series™ ratio oil pump -air operated

Có: 0 sản phẩm trong giỏ

R1000 r-series™ ratio oil pump -air operated
  • Mã SP: CP0MN-ROE
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 5986
  • suitable for 205 L (55 US gal) drums and bulk tanks
    built-in pressure relief valve
    wall mountable (stub version only)
    air line lubricator
    2” (M) bung adaptor
    fully serviceable
    10 year warranty and parts guarantee
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
  • compatible fluids: oils up to SAE 140, automatic transmission fluid, anti-freeze/anti-boil, self collapsing grease (R1000T only)
  • wetted components: aluminium, nitrile rubber, Carbon PTFE, zinc plated carbon steel
  • pump ratio: 10:1 (oil pressure is 10 times air pressure)
  • output: 15 L/min (4 US gal/min) of SAE 10 oil at 690 kPa (100 psi) air pressure (free flow)
  • max. air pressure: 1 030 kPa (150 psi, 10.3 bar)
  • min. air pressure: 400 kPa (60 psi, 4 bar)
  • min. air compressor: 0.50 m³/min (18 cfm)
  • air inlet: ¼” NPT (F)
  • pump outlet: ¾” BSP or NPT (F)
  • foot value inlet: ¾” BSP or NPT (F) (stub version)
    •
