Temperature transmitter/Temperature switch Clamp-on GS2610

Có: 0 sản phẩm trong giỏ

Temperature transmitter/Temperature switch Clamp-on GS2610
  • Mã SP: BBBLB-GS2610
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 5340
  • The temperature transmitter/temperature switch clamp-on GS is designed to monitor and regulate pipe surface temperatures especially in hygienic applications.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Features
  • Multifunctional temperature transmitter/temperature switch
  • Various clamping elements for process connection:
    - clamping block (for pipe-Ø 4…57)
    - clamping shoe (for pipe-Ø 10…300 mm)
    - clamping bracket (for pipe-Ø 4…17.2 mm)
  • Hygienic temperature measurement for pipe diameter 4…300 mm
  • Measuring system patented
  • High accuracy, fast response
  • Easy mounting
  • No welding, no interruption of process
  • No additional isolation required
  • Measuring insert can be calibrated
  • Hygienic design, constructive design according to theEHEDG recommendations
  • 4 digit LED display, can be mirror-imaged by 180°
  • Indication module can be turned through 300°
  • Measuring range -40 °C to +150 °C
  • Output signal 4…20 mA, 2-wire technology
  • Easy to program locally
  • Galvanic isolation between transmitter and switching outputs
Options
  • Parameterization via PC software COMLINE.S
  • 2 floating contacts
  • Switching contacts with high switching current (1A)
  • Calibration certificate per DIN EN 10204-3.1
  • Electrical connection rotatable by 300°
Application area

● Food industry
● Pharmaceuticals
● Biotechnology
