DCV: 0 – 600.0 V /1% ± 5 counts
ACV (True RMS): 0 – 600.0 V /1% ± 5 counts
ACA(True RMS): 0 – 600.0 A /2.0% ± 5 counts
DCA: 0 - 200.0 µA /1.0% ± 5 counts
R: 0 – 9999 Ω /1.5% ± 5 counts
Kiểm tra liên tục: có
Nhiệt độ kiểu K: -10 oC đến 400 oC (-14 oF đến 752 oF)
C: 1-1000 µF /1.9% ± 2 counts
Trọng lượng: 1.5 lbs (.7 kg)
Kích thước: 10.75” x 4.25” x 2.44” (27.3 cm x 10.8 cm x 6.2 cm)
Pin: 2xAA Alkaline
Phụ kiện: 2 pin AA Alkaline, HDSD, túi mềm, dây đo TL75, dây đo nhiệt độ 80BK
Hãng sản xuất: Fluke
Xuất xứ: trung quốc
Bảo hành: 12 tháng
Specifications
Voltage DC
Range
0 – 600.0 V
Accuracy
1% ± 5 counts
Voltage AC (True RMS)
1% ± 5 counts (50/60 Hz)
Current AC (True RMS)
0 – 600.0 A
2.0% ± 5 counts (50/60 Hz)
Current DC
0 - 200.0 µA
1.0% ± 5 counts
Resistance
0 – 9999 Ω
1.5% ± 5 counts
Continuity
<= 30 Ω
Temperature* (Type K Thermocouple)
-10 degree C to 400 degree C (-14 degree F to 752 degree F)
+/- 1.0% + 0.8 degree C (+/- 1.0% + 1.5 degree F) typical
-40 degree C to -10 degree C (-40 degree F to -14 degree F)
+/- 5.0% + 1.5 degree C (+/- 5.0% + 3.3 degree F) typical
Capacitance
1-1000 µF
1.9% ± 2 counts
Mechanical & General Specifications
Weight
1.5 lbs (.7 kg)
Dimensions
10.75” x 4.25” x 2.44” (27.3 cm x 10.8 cm x 6.2 cm)
Battery type
(2) AA Alkaline Batteries
