Cảm biến áp suất COMPACT CC60
  • Mã SP: BCBLB-COMCC60
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 6465
  • The pressure transmitter COMPACT acts as a highly accurate converter of pressure measurements to load-independent current signals (4…20 mA, for example). Special attention has been given to a hygienic design.The completely welded stainless steel housing can be designed up to protection type IP 67. The use of temperature decouplers means that the COMPACT pressure transmitter can be used for process temperatures up to 200 °C.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Features
  • Measuring ranges 0…250 mbar up to 0…100 bar
  • Linearity error including hysteresis <+ 0.2 % f.s.
  • Piezoresistive measuring system
  • Hygienic design according to EHEDG, FDA and GMPrecommendations
  • Material and surface quality according to the hygienic requirements
  • Wetted parts of stainless steel; completely welded
  • Stainless steel housing as standard or field housing
  • Degree of protection IP 65, IP 67 option
  • Output signal: 4…20 mA
  • Process temperature up to 200 °C
Options
  • Explosion protection for gases
  • Classification per SIL 2
  • Inspection certificate: material certificate as per DINEN 10204-3.1
  • Type series
    CC6010;CC6011;CC6020;CC6021
Application area

● Food industry
● Pharmaceutical industry
● Biotechnology
