Pressure transmitter PASCAL CV
  • Mã SP: BCBLB-PASCV
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 9887
  • The modular pressure transmitter PASCAL CV is suited for measuring the relative and absolute pressures of gases, vapors and liquids.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Features
  • Modular pressure transmitter with internal or flush-mounted diaphragm
    Output signal:
    ● 4…20 mA
    ● HART® protocol (rev. 6), option
    ● PROFIBUS PA, option
  • Function modules
    ● Multifunctional display with 5-segment digital display and bar graph
    ● Switching module with 2 floating channels, maximum 0.5 A switching current, electrically isolated at all sides, without additional auxiliary power
  • Function module replacement on site without recalibration “plug and measure”
  • Limits of measuring range 0…80 mbar
    to 0…400 bar
  • Accuracy: ≤ 0.15 %
  • Turndown 5:1
  • Degree of proctection IP 66, piezoresistive measuring cell directly aerated
Options
  • Explosion protection for gases and dust
  • Classification per SIL 2
  • Inspection certificates
    - material certificate as per DIN EN 10204-3.1
    - calibration certificate as per DIN EN 10204-3.1
Application area

● Chemical and petrochemical industry
● Process engineering
● General process technology
