  • Suitable for measuring liquids and gases. With open measuring flange designed for viscous media and media containing solids, too. The device is fitted with a vaccum chamber, which is sealed off from the process by a membrane. Thus, enabling absolute pressures to be measured.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền

Đồng Hồ Đo Áp Suất

Features
  • Case with blow-out device
  • Case and pressure element assembly of stainless steel
  • Highly overload protected
  • Nominal ranges 0…60 mbar abs to
    0…2500 mbar abs
  • Accuracy class 1.6 per DIN EN 837-3
Options
  • Safety case with blow-out back and solid baffle wall
  • Case with liquid filling and degree
    of protection IP 66
  • Inspection certificates
    - material certificate as per DIN EN 10204
    - calibration certificate as per DIN EN 10204
  • Type series
    BB2200;BB2300;BB2540;BB2640
Application area

● Chemical and petrochemical industry
● General process technology
● Shipping
● Machinery construction
