DL200P Professional Data Logger

Technical data:

external measurement sensor:
Surface temperature (°C/°F), material temperature (°C/°F), air temperature (°C/°F), wood moisture (digits), building material moisture (digits)

Internal sensor (temperature)

• Principle: NTC
• Measuring range: -20 °C to +50 °C
• Accuracy: ±0.3 °C (0...40 °C), otherwise 0.5 °C
• Display resolution: 0.1 °C

Internal sensor (moisture)

• Principle: capacitive
• Measuring range: 10 to 95 % RH
• Accuracy: ±2 % RH
• Display resolution: 0.5 % RH

External electrodes (wood and building moisture)**

• Principle: resistance measuring method
• Measuring range: 15 to 100 digits
• Accuracy: ± 3 digits
• Display resolution*: 1 digit

Memory organisation

• Data memory: integrated flash memory with 16 MB memory capacity (approx. 3,200,000 measuring values)
• Data logging: up to 20 measuring channels parallel

Features and dimensions

• LCD display: W 90 x H 64 mm
• Housing: synthetic material
• Dimensions: L 166 x W 32 x H 78 mm
• Weight: approx. 250 g
• Interfaces: USB, LAN
• Connecting terminals for ext. measurement sensors: 2 x 3.5 mm jack sockets (sensors) and 2 x BNC plug-in connectors (electrodes)
