Camera ảnh nhiệt EC060 V

Có: 0 sản phẩm trong giỏ

Mã SP:
Giá NY: Liên hệ
Giá bán: Liên hệ
Tình trạng: Còn hàng
Khuyến mãi:
0
Lượt xem: 7453
All the infrared cameras in the EC-Series are professional measuring instruments equipped with a standard scope of functions and features that make them ideal for a wide variety of thermographic applications. The EC060 V+ is the flagship in the series...
Tags: Bàn Map

Đơn vị tiền tệ

Số lượng:
Thành tiền

An overview of the EC060 V+’s many favourable features:

Temperature range: -20 °C to +250 °C
Accuracy: ±2 °C, ± 2% of the measured value
Detector type: Focal Plane Array (FPA), uncooled microbolometer
Detector resolution: 160 x 120 pixels
Spectral range: 8 to 14 µm
Field of Vision (FOV): 20° x 15°
Geometric resolution: 2.2 mrad
Thermal sensitivity: 0.1 °C at 30 °C
Image repetition frequency: 50/60 Hz
Focus: manual
Min. Focus Distance: 0.10 m
Digital photo camera: Colour representation 680 x 480 pixels, integrated photo lamp
Video norm: PAL
Display: 2.5-inch TFT LCD
Image display: Pseudo colours, 6 colour palettes
Laser type: Semi-conductor AlGalnP diode laser, 1 mw/635 nm red
Laser classification: Class 2
Battery type: Standard, Li-ion; rechargeable, replaceable
Operating time: ≈ 3.0 h
Mains power: 8 - 11V DC
Energy saving mode: user defined
Operating temperature: -15 °C to +50 °C
Storage temperature: -40 °C to +70 °C
Protection class: IP 54 IEC 529
Shock: 25G IEC 68-2-29
Vibration: 2G IEC 68-2-6
Dimensions: 175 x 55 x 160 mm
Weight: 500 g

More benefits at a glance:

Ten movable measuring points (9 x manual, 1 x autom. temperature tracking)
User-defined variably adjustable degree of emission from 0.01 to 1.0
Automatic measurement correction on the basis of user-defined input with regard to the surrounding temperature, distance, rel. humidity
Mini-SD card slot
14 bit radiometric IR format
Composite video out
Voice annotations can be saved with each IR image (optional)

The camera’s high image repetition frequency ensures permanent real-time image representation of thermal images and the mini SD card included in the scope of delivery can easily save thousands of thermal images.

The following accessories are included in the standard scope of delivery:

EC060 V+ with standard lens
Standard software package
Operating instructions
2GB mini SD interchangeable memory cards
Li-ion battery
Docking station
Battery charger
Video cable
Temperature test certificate
Bluetooth headset and USB cable

EC060 V+ infrared camera

The ultimate infrared camera in the EC-Series!

All the infrared cameras in the EC-Series are professional measuring instruments equipped with a standard scope of functions and features that make them ideal for a wide variety of thermographic applications. The EC 060 V+ is the flagship in the series. There is a Bluetooth headset included in the scope of delivery which provides you with a wireless means for furnishing your thermal images with voice annotations and a USB 2.0 interface which allows you to connect your infrared camera to your PC and transfer your thermographic real-time recordings and images to your computer for further assessment using the optionally available software.
