  • IC080 L infrared camera

    Equipped with a large 384 x 288 infrared sensor with 110,592 measuring spots and a geometric resolution of 1.1 mrad.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
The IC080 L's technical data:

Measurement
  • Temperature range: -20 °C to +600 °C
  • Accuracy: ±2 °C, ± 2% of the measured value


Image output radiometric
  • Detector type: Focal Plane Array (FPA), uncooled microbolometer
  • Detector resolution: 384 x 288 pixels
  • Spectral range: 7.5 to 14 µm
  • Field Of View (FOV): 24° x 21°
  • Geometric resolution: 1.1 mrad
  • Thermal sensitivity: 0.08 °C at 30 °C
  • Image refresh rate: 50/60 Hz
  • Focus: manual
  • Min. focussing distance: 0.10 m


Image representation
  • Display: 3.5 inch LCD, 320 x 240 Pixel
  • Image display: Pseudo colours, 6 colour palettes


Image storage:
  • Storage medium: interchangeable memory card slot for mini-SD card
  • Data format radiometric: 14-bit radiometric IR format
  • Data format visual: CCD
  • Voice recording: Comments can be stored with each IR image (optional Bluetooth expansion kit and Bluetooth headset necessary)


Laser
  • Type: Semiconductor AlGalnP Diode Laser, 1 mw/635 nm red
  • Classification: Class 2


Power supply
  • Battery type: Rechargeable standard lithium-ion battery, replaceable
  • Operating time: ≈2.5 h
  • Mains operation: 8 - 11V DC
  • Energy saving mode: user-defined


Ambient conditions
  • Operating temperature: -15 °C to +50 °C
  • Storage temperature: -40 °C to +70 °C
  • Air humidity: 10 % to 95 % r.H. (non-condensing)
  • Protection class: IP 54 IEC 529
  • Shockproof to: 25G IEC 68-2-29
  • Vibration-proof to: 2G IEC 68-2-6


Physical parameters
  • Dimensions: 211 x 80 x 195 mm
  • Weight: 500 g
  • Stand mounting: 1/4-inch - 20


Interfaces
  • PC: USB 2.0 (optional)
  • Video output: Composite Video

More benefits at a glance:

  • Up to four moveable measuring points (3 x manual and 1 x automatic)
  • Isotherm function (between the upper and lower limit values)
  • Variably adjustable emission factor from 0.01 to 1.0
  • Automatic measurement correction on the basis of user-defined specifications for environmental temperature, distance, relative humidity


Scope of delivery:

  • IC080 L with standard lens, LCD monitor and laser
  • 110/230 volt battery charger with charging status indicator
  • Li-ion battery
  • Mini-SD interchangeable memory card
  • Video cable
  • Operating instructions
  • Carry case
  • Software package
  • Temperature test certificate
