Turbine Wheel-Pulse-Analogue Output DPE-..F, DPE-..L

Có: 0 sản phẩm trong giỏ

Turbine Wheel-Pulse-Analogue Output DPE-..F, DPE-..L
  • Mã SP: BDLKB-DPE
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 6619
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Measuring range: 7-30 L/min ...100-750 L/min water
Connection: G ½... G 3, ½ NPT...3 NPT
Material: aluminum/bronze, st. st.
Max. pressure: 40 bar
Max. temperature: 80 °C
Accuracy: ± 2,5 % FS
Pulse output, analogue output
The KOBOLD flow meter model DPE is used for measuring and monitoring liquids. The device works according the well-known blade wheel principle. The six vane blade wheel is retained axially in a highquality saphire bearing. The sensor is supplied ready-to-install with pipe fittings or with weld-on sleeves. The blade wheel is set in motion by the flowing medium. Magnets are embedded hermetically sealed in the ends of the blade wheels. The magnets generate electrical pulses in a Hall-effect sensor mounted outside the flow area.
