● description: sinter filter centrifugal principle, diaphragm-type pressure with secundary air exhaust, lubricator with automatic oil filling
● medium: compressed air, neutral gases
● supply pressure P1 min.: 1,5 bar
● supply pressure P1 max.: 16 bar
● temperature range: 0 - 50°C (other temperature ranges available on request)
● bowl: PC with PA bowl guard
● drain: HA
● locking: lockable setting knob
● mounting: vertical
● filter element: 5 µm
● bowl volume lubricator: 80 cm³
● oil metering qv=1.000l/min: 1 - 2 drops/min
● oil type: CL 32 DIN 51517 - ISO VG 32
