Súng đo nhiệt độ TP6
  • Mã SP: TT-TP6
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 6165
  • Professional laser pyrometer from the MultiMeasure Professional series: Measurement lens 30:1, extremely wide temperature measurement range, from -50°C to +1,000°C, adjustable emissions level from 0.1 up to 1.0, high/low alarm, ...
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
The TP6 pyrometer provides a bundle of benefits in practice:
  • Contact-free surface temperature measurements between -50 °C and +1,000 °C
  • Optical resolution 30:1
  • Sheer unbeatable value for money
  • Dual laser technology for measuring spot diameter display
  • Freely-selectable degree of emission from 0.1 to 1.0
  • Minimum/maximum value and hold function
  • Backlit display
  • Alarm
  • Auto power off


Technical data

  • Optical resolution (D:S): 30:1
  • Temperature range: -50° to 1,000 °C
  • Resolution: 0.1 °C


  • Accuracy (surrounding temperature from 23 to 25 °C):
± 2.5 °C at -50 °C to 20 °C
± 1 % of measured value at 21 °C to 300 °C
± 1.5 % of measured value at 301 °C to 1,000 °C

  • Reproducibility:
± 1.3 °C at -50 °C to 20 °C
± 0.8 % or ± 0.5 °C at 21 °C to 1,000 °C

  • Smallest measurement spot ø: 25.4 mm @ 762 mm
  • Reaction time: < 150 ms
  • Degree of emission: Adjustable from 0.10 to 1.0
  • Spectral sensitivity: 8 ~ 14 µm
  • Operating conditions: 0 °C to 50 °C, 10 % to 90 % r.h.
  • Storage conditions: -10 °C to 60 °C, < 80 % r.h.
  • Power supply: 9V block battery
  • Dimensions: 104 x 43 x 146 mm
  • Weight: 163 g
TP6 pyrometer– the universal infrared thermometer for a sheer multitude of applications

The TP6 professional pyrometer is equipped with an exhaustive list of impressive features which make it ideal for a variety of different professional applications. There’s the temperature range which spans over a thousand degrees allowing you to measure temperatures between -50 °C and +1,000 °C, an optical resolution of 30:1 and a state-of-the-art dual laser designed to visualize measuring spots and provide you with an optimum of comfort. And then there’s the price. The TP6 is not just a good buy – it is quite simply excellent value for money. Which is what you have long come to expect from Trotec.

When our technicians designed the TP6 they had a clear vision of what they wanted: a brilliant backlit display that would make it easy to read off the values in both favourable conditions as well as in dimly-lit surroundings and a degree of emission that could be adjusted individually to suit the type of material that had been selected for measuring. Now isn’t that what you would have wanted too?

The TP6 is ideal for a sheer endless number of professional applications: it is tough enough to stand up to the rigours and demands of daily use and compact enough for use in hard-to-reach or virtually inaccessible places. And because of the extremely high temperature measuring range and the contact-free measuring principle it is excellently suited for measuring the temperatures of hot, moving or even dangerous measuring targets.
