Diaphragm pressure gauge BE2
  • Mã SP: BCCLB-BE2
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 6437
  • Can be used as an excess pressure gauge with electrical contact device for measuring liquids and gases. Because of its robust design, it is suitable for use in tough environments.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Features
  • Case with blow-out device
  • High excess-pressure protection up to 5 times (option: up to 20 times)
  • Case and pressure element assembly of stainless steel, diaphragm of Duratherm
  • Nominal range 0…25 mbar up to 0…25 bar
  • Accuracy class per DIN 16085
  • Electrical contact device per DIN 16085:
    - slow acting contact
    - magnetic snap contacts
    - inductive contact devices
Options
  • Explosion protection
  • Safety case with solid baffle wall and blow-out back
  • Case with liquid filling and degree
    of protection IP 66
  • Classification per SIL 2
  • Approval to German Lloyd
  • Connection to Zone 0
  • Material certificate per DIN EN 10204
  • Type series
    BE2200;BE2201;BE2220;BE2221;BE2300;BE2301
    BE2320;BE2321;BE2500;BE2501;BE2540;BE2541
    BE2600;BE2601;BE2640;BE2641
Application area

● Chemical and petrochemical industry
● Shipping
● Machinery construction
