Differential pressure gauge BG2
  • Mã SP: BCCLB-BG2
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 6114
  • Differential pressure gauges with electrical contact device for level measuring, filter monitoring and flow measuring under severe operating conditions
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Features
  • Case with blow-out device
  • Case and measuring flange of stainless steel, diaphragm of Duratherm
  • High overload protection up to 5 times (option: up to 20 times)
  • Nominal range 0…40 mbar up to 0…25 bar (differential pressure)
  • Accuracy class per DIN 16085
  • Electrical contact device per DIN 16085:
    - slow acting contact
    - magnetic snap contact
    - inductive contact device
Options
  • Explosion protection
  • Safety pattern gauge with solid baffle wall and blow-out back
  • Approval German Lloyd
  • 3-way valve block
  • Connection per zone 0
  • Material certificate per DIN EN 10204
  • Oxygen free of oil and grease
  • Type series
    BG2200;BG2201;BG2220;BG2221
    BG2300;BG2301;BG2320;BG2321
    BG2500;BG2501;BG2540;BG2541
    BG2600;BG2601;BG2640;BG2641
Application area

● Chemical and petrochemical industry
● Shipping
● Machinery construction
