Cảm biến áp suất COMPACT CC60C
  • Mã SP: BCBLB-CC60
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 6723
  • The pressure transmitter COMPACT acts as a highly accurate converter of pressure measurements to load-independent current signals. Because of various variants of process connections and materials these transmitters are especially suited for pressure measurement with aggressive, highly viscous, solidifying or crystallizing media.The completely welded stainless steel housing can be designed up to protection type IP 67. The use of temperature decouplers means that the COMPACT pressure transmitter can be used for process temperatures up to 200 °C.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Features
  • Measuring ranges 0…250 mbar up to 0…400 bar
  • Linearity error including hysteresis <+ 0.2 % f.s.
  • Piezoresistive measuring system
  • Separating foil from stainless steel or special materials
  • Completely encapsulated electronics
  • Stainless steel housing as standard or field housing
  • Degree of protection IP 65, IP 67 option
  • Output signal: 4…20 mA
  • Process temperature up to 200 °C
Options
  • Explosion protection for gases
  • Classification per SIL 2
  • Inspection certificate: material certificate as per DINEN 10204-3.1
  • Type series
    CC6010;CC6011;CC6020;CC6021
Application area

● Chemical industry
● Petrochemical industry
