Pressure transmitter PASCAL CVK80
  • Mã SP: BCBLB-CVK80
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 5126
  • The modular pressure transmitter PASCAL CV is suited for measuring the relative and absolute pressures of gases, vapors and liquids. The use of a HYGIENIC process adapter allows the device to be deployed in a variety of processes. The design based on module technology/variable adapter means lower inventories over the longer term.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
  • Modular pressure transmitter with diaphragm sealtechnology
  • Output signal:
    ● 4…20 mA
    ● HART® protocol (rev. 6), option
    ● PROFIBUS PA, option
  • Function modules
    ● Multifunctional display with 5-segment digital display and bar graph
    ● Switching module with 2 floating channels, maximum 0.5 A switching current, electrically isolated at all sides, without additional auxiliary power
  • Function module replacement on site without recalibration “plug and measure”
  • Limits of measuring range 0.2 bar to 40 bar
  • Accuracy: ≤ 0.15 %
  • Turndown 5:1
  • Degree of protection IP 66, piezoresistive measuring cell directly aerated
  • Hygienic design according to EHEDG, FDA and GMPrecommendations
  • Material and surface quality according to the hygienic requirements
  • G1A process adapter with elastomer-free hygienic process connection, rotary thread adapter suitable for HYGIENIC process adapter
Options
  • Explosion protection for gases and dust
  • Classification per SIL 2
  • Inspection certificates
    - material certificate as per DIN EN 10204-3.1
    - calibration certificate as per DIN EN 10204-3.1
Application area

● Food industry
● Pharmaceutical industry
● Biotechnology
