Pressure transmitter/pressure switch PASCAL CS2110

Có: 0 sản phẩm trong giỏ

Pressure transmitter/pressure switch PASCAL CS2110
  • Mã SP: BCBLB-PASCS2110
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 4930
  • The pressure transmitter/pressure switch PASCAL CS is suited for measuring the relative and absolute pressures of gases, vapors and liquids. The multifunctional PASCAL CS displays the measurement; outputs a current signal proportional to the pressure. It has two optional contacts
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Features
  • Multifunctional pressure transmitter/pressure switch
  • Hygienic case with no notches or indentations
  • Degree of protection IP 65
  • 4 digit LED display, can be mirror-imaged by 180°
  • Indication module can be turned through 300°
  • Measuring ranges 0…100 mbar to 0…40 bar rel., 0…1 bar to 0…6 bar abs
  • Output signal 4…20 mA, 2-wire technology
  • Accuracy: ≤ 0.2 %
  • Easy to program locally (as per VDM standard)
  • Galvanic isolation between transmitter and switching outputs
  • Various process connections with flush mounted diaphragm
Options
  • Parameterization via PC software for devices with contacts available
  • 2 floating contacts
  • Switching contacts with high switching current (1A)
  • Hygienic design
  • Inspection certificates
    - material certificate per DIN EN 10204-3.1
    - calibration certificate per DIN EN 10204-3.1
    - roughness height rating
  • Wetted parts electropolished
  • Electrical connection rotatable by 300°
  • Degree of protection IP 67
Application area

● Food industry
● Pharmaceutical industry
● Biotechnology
