DCV: 50.000 mV,500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0V /0.025 %
ACA (True RMS): 50.000 mV,500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0V /0.4 %
DCA: 500.00 µA, 5000.0 µA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A /0.06 %
ACA (True RMS):500.00 µA, 5000.0 µA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A /0.6%
Nhiệt độ: -200.0 °C đến 1350.0 °C (-328.0 °F đến 2462.0 °F) (option probe)
R: 500.00 Ω, 5.0000 kΩ, 50.000 kΩ, 500.00 kΩ, 5.0000 MΩ, 50.00 MΩ, 500.0 MΩ /0.05 %
C: 1.000 nF,10.00 nF 100.0 nF, 1.000 µF, 10.00 µF, 100.0 µF, 1000 µF, 10.00 mF, 100.00 mF /1.0 %
F: 99.999 Hz, 999.99 Hz, 9.9999 kHz, 99.999 kHz, 999.99 kHz /0.005%
Băng tần (True-rms) AC : 100 kHz
DBV/dBm: có
Độ dẫn điện : 50.00nS
Kiểm tra liên tục: có
Giá trị đỉnh: 250 μS
Đồng hồ thời gian: có
Min-Max-Avg: có
Chu kỳ: 0.01 % đến 99.99 %
Độ rộng xung: 0.025 ms, 0.25 ms, 2.5 ms, 1250.0 ms
Hold : có
Giao tiếp quang: có
Auto/Touch Hold: có
Bộ nhớ: có
Log to PC: có
Interval/Event Logging: có
Bộ nhớ: 10,000 giá trị
Kích thước: (HxWxL 22.2 cm x 10.2 cm x 6 cm
Trọng lượng: 870.9 g (28 oz)
Pin: 6 pin AA
Phụ kiện: HDSD, 6 pin AA, dây đo TL71, kẹp cá sấu AC175
Hãng sản xuất: Fluke
Xuất xứ: Mỹ
Bảo hành: 12 tháng
Specifications
Voltage DC
Accuracy
0.025 %
Range and Resolution
50.000 mV,500.00 mV, 5.0000 V, 50.000 V, 500.00 V, 1000.0V
Voltage AC
0.4 %(true-rms)
Current DC
0.06 %
500.00 µA, 5000.0 µA, 50.000 mA, 400.00 mA, 5.0000 A, 10.000 A
Current AC
0.6%(true-rms)
Temperature (excluding probe)
1.0 %
-200.0 °C to 1350.0 °C (-328.0 °F to 2462.0 °F)
Resistance
0.05 %
500.00 Ω, 5.0000 kΩ, 50.000 kΩ, 500.00 kΩ, 5.0000 MΩ, 50.00 MΩ, 500.0 MΩ
Capacitance
1.000 nF,10.00 nF 100.0 nF, 1.000 µF, 10.00 µF, 100.0 µF, 1000 µF, 10.00 mF, 100.00 mF
Frequency
0.005% + 5
99.999 Hz, 999.99 Hz, 9.9999 kHz, 99.999 kHz, 999.99 kHz
Additional functions/features
Multiple on-screen displays
Yes
True-rms AC bandwidth
100 kHz
DBV/dBm
Conductance
50.00nS
Continuity beeper
Battery/Fuse access
Battery / Fuse
Peak
250 μS
Elapse time clock
Time of day clock
Min-Max-Avg
Duty Cycle
0.01 % to 99.99 %
Pulse Width
0.025 ms, 0.25 ms, 2.5 ms, 1250.0 ms
Hold
Isolated Optical Interface
Auto/Touch Hold
Reading memory
Log to PC
Interval/Event Logging
Logging Memory
Up to 10,000 readings
Environmental Specifications
Operating Temperature
-20 °C to +55 °C
Storage Temperature
-40 °C to +60 °C
Relative Humidity
0% to 90% (0 °C - 37 °C)
0% to 65% (37 °C - 45 °C),
0 to 45 % (45 °C - 55 °C
Electromagnetic Compatability
EMC EN6 1326-1
Vibration
Random vibration per MIL-PRF-28800f Class 2
Shock
1 meter drop per IEC/EN 61010-1 2nd edition
Safety Specifications
Overvoltage category
CAT III 1000 V / CAT IV 600 V safety rated
Agency Approvals
CSA, UL, TÜV, CE
Mechanical & General Specifications
Maximum voltage between any terminal and earth ground
1000V
Size
(HxWxL 22.2 cm x 10.2 cm x 6 cm (8.75 in x 4.03 in x 2.38 in)
Weight
870.9 g (28 oz)
Battery Life
100 minimum, 200 hours in logging mode
Battery type
6 AA alkaline batteries, NEDA 15A IEC LR6
