Measuring range: 0,5-12 L/min ...10-140 L/min water
Connection: G 1/8... G 1, 1/8 NPT.. 1 NPT
Material: aluminum-bronze, st. st., Polypropylen
Max. pressure: 40 bar
Max. temperature: 80 °C
Accuracy: ± 3 % FS
Pulse output, analogue output
 Rotating vane flow meters series DRG are used for measuring and monitoring low viscous liquids. Series DRG flow meters are working according the wellknown rotating vane principle. A magnet fitted in the vane and hermetically sealed from the medium transfers non-contacting the rotary motion to a Hall-effect sensor mounted in the housing. The sensor converts the rotary motion which is proportional to the flow to a frequency signal. A series-connected electronics unit converts the signal to an analogue output, limit contacts or display.
