Rotating Vane-Pulse-Analogue Output DRH-..F, DRH-..L

Có: 0 sản phẩm trong giỏ

Rotating Vane-Pulse-Analogue Output DRH-..F, DRH-..L
  • Mã SP: BDJKB-DRH
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 6824
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Measuring range: 0,2-0,8 L/min ...2,5-50 L/min water
Connection: G 3/8, G 1, 3/8 NPT, 1 NPT
Material: brass, st. st., POM, PVDF
Max. pressure: 100 bar
Max. temperature: 100 °C
Accuracy: ± 2,5 % FS
Pulse output, analogue output
Rotating vane flow meters series DRH are used for measuring and monitoring low viscous liquids. Series DRH flow meters are working according the wellknown rotating vane principle. A magnet fitted in the vane and hermetically sealed from the medium transfers non-contacting the rotary motion to a Hall-effect sensor mounted in the housing. The sensor converts the rotary motion which is proportional to the flow to a frequency signal. A series-connected electronics unit converts the signal to an analogue output, limit contacts or display. This devices can be adapted to prevailing plant conditions with the 360° rotatable screw connections.
