  • IC080 LV infrared camera

    The fully-radiometric IC 080 V infrared camera is only available in a fixed number. So be quick off the mark and take advantage of unbelievably priced demo models with as good as new characteristics.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
The IC080 LV's technical data:

Measurement
  • Temperature range: -20 °C to +600 °C
  • Accuracy: ±2 °C, ± 2% of the measured value


Image output radiometric
  • Detector type: Focal Plane Array (FPA), uncooled microbolometer
  • Detector resolution: 384 x 288 pixels
  • Spectral range: 7.5 to 14 µm
  • Field Of View (FOV): 24° x 21°
  • Geometric resolution: 1.1 mrad
  • Thermal sensitivity: 0.08 °C at 30 °C
  • Image refresh rate: 50/60 Hz
  • Focus: manual
  • Min. focussing distance: 0.10 m


Image performance visual
  • Digital photo camera: Colour depiction 680 x 480 Pixel,integrated photo lamp
  • Video norm: PAL


Image representation
  • Display: 3.5 inch LCD, 320 x 240 Pixel
  • Image display: Pseudo colours, 6 colour palettes
  • Image display options: IR image, real image, different DuoVision options for combined display of IR and real imaged


Image storage:
  • Storage medium: interchangeable memory card slot for mini-SD card
  • Data format radiometric: 14-bit radiometric IR format
  • Data format visual: CCD
  • Voice recording: Comments can be stored with each IR image (optional Bluetooth expansion kit and Bluetooth headset necessary)


Laser
  • Type: Semiconductor AlGalnP Diode Laser, 1 mw/635 nm red
  • Classification: Class 2


Power supply
  • Battery type: Rechargeable standard lithium-ion battery, replaceable
  • Operating time: ≈2.5 h
  • Mains operation: 8 - 11V DC
  • Energy saving mode: user-defined


Ambient conditions
  • Operating temperature: -15 °C to +50 °C
  • Storage temperature: -40 °C to +70 °C
  • Air humidity: 10 % to 95 % r.H. (non-condensing)
  • Protection class: IP 54 IEC 529
  • Shockproof to: 25G IEC 68-2-29
  • Vibration-proof to: 2G IEC 68-2-6


Physical parameters
  • Dimensions: 230 x 80 x 195 mm
  • Weight: 650 g
  • Stand mounting: 1/4-inch - 20


Interfaces
  • PC: USB 2.0 (optional)
  • Video output: Composite Video


More benefits at a glance:

  • Up to four moveable measuring points (3 x manual and 1 x automatic)
  • Isotherm function (between the upper and lower limit values)
  • Variably adjustable emission factor from 0.01 to 1.0
  • Automatic measurement correction on the basis of user-defined specifications for environmental temperature, distance, relative humidity


Scope of delivery:
  • IC080 LV with standard lens, LCD monitor and laser
  • 110/230 volt battery charger with charging status indicator
  • Li-ion battery
  • Mini-SD interchangeable memory card
  • Video cable
  • Operating instructions
  • Carry case
  • Software package
  • Temperature test certificate


*requires optional Bluetooth expansion and optional Bluetooth headset!

Please NOTE! We only have a fixed number IC080 V demonstration models. This special offer is only valid while stocks last!
Your benefits:

  • As good as new units, boxed as new
  • Have always been used under the strict supervision of schooled Trotec staff
  • All products have been subjected to quality testing by trained technicians
  • Technically sound and in excellent shape
  • No outward defects
  • Full warranty


Magnificiently magnifying and very variable: The IC080 LV

This infrared camera in the LV model range leaves nothing to be desired and expands the benefits of the V models and provides a high-performance 384 x 288 infrared sensor with 110,592 temperature measuring points.

In addition, the IC080 LV distinguishes itself with an extremely high geometric resolution of 1.1 mrad.

An integrated real image camera, a photo lamp and a DuoVision display option which allows an overlapping of the infrared and the real image in real-time all come as standard with this infrared camera.

In addition, it has Bluetooth connectability for wireless voice recordings via headset. *

The integrated memory card slot provides for quick and comfortable memory management and the mini-SD card that is included in the scope of delivery can comfortably store thousands of images.

The comprehensive software package enables the user to perform substantive analyses and compile informative assessment reports.
