  • IC080 V Infrared Camera + Thermo Software Professional + Tripod Mount

    Don’t miss the benefits of the thermo software professional and enlarge your camera’s field of use due to the possibilities of tripod mount.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
The IC080 V's technical data:

Measurement
  • Temperature range: -20 °C to +600 °C
  • Accuracy: ±2 °C, ± 2% of the measured value


Image output radiometric
  • Detector type: Focal Plane Array (FPA), uncooled microbolometer
  • Detector resolution: 160 x 120 pixels
  • Spectral range: 8 to 14 µm
  • Field Of View (FOV): 20° x 15°
  • Geometric resolution: 2.2 mrad
  • Thermal sensitivity: 0.1 °C at 30 °C
  • Image refresh rate: 50/60 Hz
  • Focus: manual
  • Min. focussing distance: 0.10 m


Image performance visual
  • Digital photo camera: Colour depiction 680 x 480 Pixel,integrated photo lamp
  • Video norm: PAL


Image representation
  • Display: 3.5 inch LCD, 320 x 240 Pixel
  • Image display: Pseudo colours, 6 colour palettes
  • Image display options: IR image, real image, different DuoVision options for combined display of IR and real imaged


Image storage:
  • Storage medium: interchangeable memory card slot for mini-SD card
  • Data format radiometric: 14-bit radiometric IR format
  • Data format visual: CCD
  • Voice recording: Comments can be stored with each IR image (optional Bluetooth expansion kit and Bluetooth headset necessary)


Laser
  • Type: Semiconductor AlGalnP Diode Laser, 1 mw/635 nm red
  • Classification: Class 2


Power supply
  • Battery type: Rechargeable standard lithium-ion battery, replaceable
  • Operating time: ≈2.5 h
  • Mains operation: 8 - 11V DC
  • Energy saving mode: user-defined


Ambient conditions
  • Operating temperature: -15 °C to +50 °C
  • Storage temperature: -40 °C to +70 °C
  • Air humidity: 10 % to 95 % r.H. (non-condensing)
  • Protection class: IP 54 IEC 529
  • Shockproof to: 25G IEC 68-2-29
  • Vibration-proof to: 2G IEC 68-2-6


Physical parameters
  • Dimensions: 230 x 80 x 195 mm
  • Weight: 650 g
  • Stand mounting: 1/4-inch - 20


Interfaces
  • PC: USB 2.0 (optional)
  • Video output: Composite Video


More benefits at a glance:

  • Up to four moveable measuring points (3 x manual and 1 x automatic)
  • Isotherm function (between the upper and lower limit values)
  • Variably adjustable emission factor from 0.01 to 1.0
  • Automatic measurement correction on the basis of user-defined specifications for environmental temperature, distance, relative humidity


Scope of delivery:

  • IC080V with standard lens, LCD monitor and laser
  • 110/230 volt battery charger with charging status indicator
  • Li-ion battery
  • Mini-SD interchangeable memory card
  • Video cable
  • Operating instructions
  • Carry case
  • Software package
  • Temperature test certificate


* requires optional Bluetooth expansion and optional Bluetooth headset!

This super package deal includes the thermo software professional and a tripod mount for IC infrared cameras.

The professional software allows you to carry out extensive researches with the thermal images you recorded with your Trotec infrared camera.Create detailed reports for your customers and benefit from the easy-to-use functions and features.

Due to the tripod mount your IC infrared camera is now prepared for long-term measurements in cases where the device mustn’t be moved for instance to do researches on electrical plants, buildings or other objects from exact the same point and angle of view. This also enables a huge advantage in analysing the thermal images on-site directly on your infrared camera.
V as in more variety: The IC080 V infrared camera

This infrared camera from the V model range in the Trotec IC Series takes even more of an in depth view of your measuring objects.

In contrast to the standard models, the IC080V also has an integrated real image camera, a photo lamp and a DuoVision display option which allows an overlapping of the infrared and the real image in real-time.

In addition, it has Bluetooth connectability for wireless voice recordings via headset .*

The comprehensive software package enables the user to perform substantive analyses and compile informative assessment reports.
