IC120 V Infrared Camera
  • Mã SP:
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 7133
  • This infrared camera from the V model range in the Trotec IC Series has an extremely wide temperature measuring range of -20 °C to +1,500 °C takes even more of an in depth view of your measuring objects.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
The IC120 V's technical data:

Measurement
  • Temperature range: -20 °C to +1,500 °C
  • Accuracy: ±2 °C, ± 2% of the measured value


Image output radiometric
  • Detector type: Focal Plane Array (FPA), uncooled microbolometer
  • Detector resolution: 160 x 120 pixels
  • Spectral range: 8 to 14 µm
  • Field Of View (FOV): 20° x 15°
  • Geometric resolution: 2.2 mrad
  • Thermal sensitivity: 0.1 °C at 30 °C
  • Image refresh rate: 50/60 Hz
  • Focus: manual
  • Min. focussing distance: 0.10 m


Image performance visual
  • Digital photo camera: Colour depiction 680 x 480 Pixel,integrated photo lamp
  • Video norm: PAL


Image representation
  • Display: 3.5 inch LCD, 320 x 240 Pixel
  • Image display: Pseudo colours, 6 colour palettes
  • Image display options: IR image, real image, different DuoVision options for combined display of IR and real imaged


Image storage:
  • Storage medium: interchangeable memory card slot for mini-SD card
  • Data format radiometric: 14-bit radiometric IR format
  • Data format visual: CCD
  • Voice recording: Comments can be stored with each IR image (optional Bluetooth expansion kit and Bluetooth headset necessary)


Laser
  • Type: Semiconductor AlGalnP Diode Laser, 1 mw/635 nm red
  • Classification: Class 2


Power supply
  • Battery type: Rechargeable standard lithium-ion battery, replaceable
  • Operating time: ≈2.5 h
  • Mains operation: 8 - 11V DC
  • Energy saving mode: user-defined


Ambient conditions
  • Operating temperature: -15 °C to +50 °C
  • Storage temperature: -40 °C to +70 °C
  • Air humidity: 10 % to 95 % r.H. (non-condensing)
  • Protection class: IP 54 IEC 529
  • Shockproof to: 25G IEC 68-2-29
  • Vibration-proof to: 2G IEC 68-2-6


Physical parameters
  • Dimensions: 230 x 80 x 195 mm
  • Weight: 650 g
  • Stand mounting: 1/4-inch - 20


Interfaces
  • PC: USB 2.0 (optional)
  • Video output: Composite Video


More benefits at a glance:

  • Up to four moveable measuring points (3 x manual and 1 x automatic)
  • Isotherm function (between the upper and lower limit values)
  • Variably adjustable emission factor from 0.01 to 1.0
  • Automatic measurement correction on the basis of user-defined specifications for environmental temperature, distance, relative humidity


Scope of delivery:
  • IC120 V with standard lens, LCD monitor and laser
  • 110/230 volt battery charger with charging status indicator
  • Li-ion battery
  • Mini-SD interchangeable memory card
  • Video cable
  • Operating instructions
  • Carry case
  • Software package
  • Temperature test certificate


* requires optional Bluetooth expansion and optional Bluetooth headset!
Variety and flexibility combined: The IC120 V infrared camera

This infrared camera from the V model range in the Trotec IC Series has an extremely wide temperature measuring range of -20 °C to +1,500 °C takes even more of an in depth view of your measuring objects.

In contrast to the standard models, the IC120 V also has an integrated real image camera, a photo lamp and a DuoVision display option which allows an overlapping of the infrared and the real image in real-time.

In addition, it has Bluetooth connectability for wireless voice recordings via headset. *

The comprehensive software package enables the user to perform substantive analyses and compile informative assessment reports.
