Life Science Microscopes Crocus 5MP MCX100

Có: 0 sản phẩm trong giỏ

Life Science Microscopes Crocus 5MP MCX100
  • Mã SP: CFAMC-5MP
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 5879
  • MCX100 Body available as Halogen or LED version

    Quintuple reverse-angle ball-bearing nosepiece

    Low position coaxial coarse and calibrated fine focus control
    Incorporated tension adjustment and safety autofocus stop unit
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
MCX100 Body available as Halogen or LED version

Quintuple reverse-angle ball-bearing nosepiece

Low position coaxial coarse and calibrated fine focus control
Incorporated tension adjustment and safety autofocus stop unit

Double layer specimen stage (160 x 140 mm) with exchangeable, ultra-hardened, flexible glass plate and right handed mechanical stage, moving range 72 x 50 m

Trinocular head, 30° inclined, interpupillary distance 55-75 mm
Eyepieces EWF10x/20 Widefield with diopter adjustment and eye shields

Infinity corrected ICO Plan Objectives
ICO² Plan 4/0.10 W.D. 17,8 mm
ICO² Plan 10/0.25 W.D. 17,96 mm
ICO² Plan 40/0.65 W.D. 4,5 mm, spring loaded
ICO² Plan 100/1.25 oil, W.D. 1,81 mm spring loaded

Abbé condensor n.A. 1.25, with iris diaphragma
Aperture diaphragm with positive guide marking for respective objectives

Koehler Illumination System 20W Halogen
