Life Science Microscopes Orchid MCX300
  • Mã SP: CFAMC-MCX300
  • Giá NY: Liên hệ
  • Giá bán: Liên hệ
  • Tình trạng:
  • Khuyến mãi:
  • Lượt xem: 5815
  • MCX300 Main body with 6V30W halogen for 220V/50Hz or 110V/60Hz

    Quintuple reverse-angle ball-bearing nosepiece

    Low position coaxial coarse and calibrated fine focus control

    Incorporated tension adjustment and safety autofocus stop unit
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
MCX300 Main body with 6V30W halogen for 220V/50Hz or 110V/60Hz

Quintuple reverse-angle ball-bearing nosepiece

Low position coaxial coarse and calibrated fine focus control

Incorporated tension adjustment and safety autofocus stop unit

Double layer specimen stage (160 x 140 mm) with exchangeable, ultra-hardened, flexible glass plate and right handed mechanical stage, moving range 72 x 50 mm

Compensation binocular or trinocular head, 30° inclined, 360° rotatable,
interpupillary distance 55-75 mm

Eyepieces EWF10x/20 Widefield with diopter adjustment and eye shields

Infinity Corrected ICO PLAN Objectives
ICO² PLAN 4/0.10 W.D. 17,8 mm
ICO² PLAN 10/0.25 W.D. 10 mm
ICO² PLAN 40/0.65, spring loaded W.D. 0,35 mm
ICO² PLAN 100/1.25 oil, spring loaded W.D. 0,13 mm

Abbé condensor n.A. 1.25, with iris diaphragma
Aperture diaphragm with positive guide marking for respective objectives
Koehler Illumination System 30W Halogen

Delivery with blue filter, dust cover, immersion oil, 2 spare bulbs Philips 30W and instruction manual

Options: ERGO head with variable inclination from 5° to 35°, various eyepieces, phase contrast, polarization, darkfield, fluorescence, photo/video adapters, digital cameras, Sliding Stage, aluminium carrying case, etc
