  • Eclipse AH-MA v2.20 Air Heat burners are ideal for heating fresh air in make-up and process air heating applications. They produce a uniform, odorless, and smokeless flame. The AH-MA design provides stable operation over a wide range of velocities, inputs and fuels.

    AH-MA v2.20 burners are line type burners constructed of cast iron or aluminum burner bodies and diverging stainless steel air wings. The burner bodies supply fuel to the center of the air wings to control the air and fuel mixture inside the burner and to optimize emissions and efficiency. Completely corrosion resistant design options are available using aluminum burner bodies or electroless nickel plated cast iron burner bodies.
  • Tags: Bàn Map
Đơn vị tiền tệ
  • Số lượng:
  • Thành tiền
Current Version: 2.2
Type:  Nozzle Mixing
Number of Sizes:  Modular
Capacity Range:   1,200,000 (Btu/hr/LF)
1150 (kW/m)
Turndown:  30:1
Max. Process Temperature:  850°F, 454°C
Fuels:  Natural Gas, Propane, Butane
Typical Applications:

Make-up air heating

Drying Processes
Key Attributes:  Robust, reliable performance. Compact modular design.
  • Assembled from straight sections, tees and crosses to produce nearly any configuration required.
  • Large burners can be built as a combination of staged, individually controlled sections to increase turndown.
  • Inputs up to 1,200,000 Btu/hr/LF
  • Up to 30:1 turndown
  • Up to 450°F upstream air temperature.
  • Up to 850°F downstream air temperature.
  • Multi-fuel capability (natural gas, propane and butane)
