High Performance Burners For Process Air Heating

The world’s most reliable air heating burner is safe and simple to operate. The RatioMatic design takes the guesswork out of start-up and adjustment. Eclipse engineers found a way to simplify burner start-up and adjustment, while offering more packaging options for greater flexibility in operation…worldwide.
Tags: Bàn Map

Đơn vị tiền tệ

Current Version:	5.1
Type:	Nozzle Mixing
Number of Sizes:	14
Capacity Range:	500,000 to 30,000,000 (Btu/hr) 147 to 8785 (kW)
Turndown:	21:1 up to 100:1
Max. Process Temperature:	1900°F, 1038°C
Fuels:	Natural Gas, Propane, Butane
Typical Applications:	Dry-off and curing ovens Incinerators Indirect air heating Textile drying Food processing/baking Annealing Aluminum homogenizing
Key Attributes:	Easy set-up. No gas adjustment with ratio control. Safety you can trust. Robust, reliable performance.

Compare RatioMatic features to any competitive model:

RatioMatic design takes the guesswork out of start-up and adjustment.
Ratio regulator automatically compensates for changes in operating conditions.
Turndown range of up to 100:1.
Direct-drive air butterfly eliminates linkages which can slip or jam during operation.
Fast-mixing nozzle provides clean stable flame at all firing rates and releases heat into the chamber, not the oven wall.
Ideal for emission-sensitive processes due to low NOx, CO and aldehydes.
Capacities from 500,000 to 30,000,000 Btu/hr.
